Reverse Osmosis System Water Treatment Plant

King Machine Co., Ltd. is one of the most experienced manufacturers and suppliers of reverse osmosis system water treatment plant in China. Please feel free to buy high quality machines for sale here from our factory. Good service and reasonable price are available.

Reverse Osmosis System Water Treatment Plant

Raw water: Raw water quality analysis report (preferably provided for production use)

Raw water: groundwater

Production water application: pesticide manufacturing

Water production volume: 100L/H-50000L/H

System configuration: pre-treatment + one-step RO water purification system + post-treatment

Design recovery rate: 65%

Rejection rate: ≥97%

Up to 12 hours per day and 350 working days per year

Installation conditions: internal system installation; temperature: 5～45℃

Voltage: 220 volts/380 volts, 50 Hz/60 Hz;

Water outlet standard: Inlet water conductivity 500μs/cm, water conductivity ≤10μs/cm (desalination rate 98-99.8%).

work process

1. Raw water pump-provide pressure for quartz sand filter/activated carbon filter.

2. Multi-media filter-remove turbidity, suspended matter, organic matter, colloid, etc.

3. Activated carbon filter-remove color, free chloride, organic matter, harmful substances, etc.

4. Softener-exchange calcium and magnesium "ions" in the most common and simple way.

5. Micron filter-prevent large particles, bacteria, and viruses in the RO membrane, with an accuracy of 5um,

6. High pressure pump-provides high pressure to the RO diaphragm.

7. The main part of RO equipment. The RO membrane desalination rate can reach 99%, and the ion removal rate is more than 99%.
